EN 10216-1, P235TR1, Seamless steel tubes for pressure purposes Part 1: Non-alloy steel tubes with specified room temperature properties, Carbon steel pipe, structural steel pipe

EN 10216-1 Seamless steel tubes for pressure purposes Part 1: Non-alloy steel tubes with specified room temperature properties

Standard: EN 10216-1
Equivalent Standard: DIN 1629

Material: P235TR1, 1.0254
Equivalent Materials: St37, 1010, 360, 10

Chemistry Composition

C, %	Si, %	Mn, %	P, %	S, %	Cr, %	Ni, %	Cu, %	Mo, %	Nb, %	Ti, %	V, %
0.16 max	0.35 max	1.20 max	0.025 max	0.020 max	0.30 max	0.30 max	0.30 max	0.08 max	0.01 max	0.04 max	0.02 max

Mechanical Properties

Tensile Strength , MPa	Yield Strength, MPa	Elongation, %
360-500	235 min	25 min

Outside Diameter & Tolerance

Outside Diameter, mm	Tolerance
OD≤219.1	±1%, 0.5mm min
OD>219.1	±1%, 0.5mm min

Wall thickness & Tolerance

Outside Diameter, mm	WT/OD	Tolerance
OD≤219	WT/OD≤2.5%	±12.5% or ±0.4mm
	2.5%＜WT/OD≤5%
	5%＜WT/OD≤10%
	WT>10%
OD>219.1	WT/OD≤2.5%	±20%
	2.5%＜WT/OD≤5%	±15%
	5%＜WT/OD≤10%	±12.5%
	WT/OD>10%	±10%

EN 10216 part 1 specifies the technical delivery condition for two qualities TR1 and TR2 of seamless tubes of circular cross section with specified room temperature properties made of non-alloy quality steel.

Manufacture: tubes to EN 10216-1 shall be manufactured by hot formed or cold finished.
Heat Treatment: the tubes shall be supplied in normalized or normalising-formed delivery condition.
Inspection & Test: tensile test, NDT, surface inspection and dimension check.
Optional Test: impact test for TR2.

Length: 5800mm; 6000mm; 10000mm; 11800mm; and so on.
Max length: 18000mm

Keyword: seamless steel pipe, seamless steel tube, EN 10216-1
